Macho Prensar BSPP 60 VITILLO

Conector: Macho
Rosca: BSPP
Tipo: Estándar

Réf.	Ref. Vitillo	D.N.	A	P. Trabajo	Hexágono	Para Manguera	Rosca
06110-03-02	MG0302	5	20,5 mm	350 bar 5075 psi	14 mm	4,8 mm 3/16"	1/8"
06110-03-04	MG0304	5	26 mm	415 bar 6010 psi	19 mm	4,8 mm 3/16"	1/4"
06110-04-02	MG0402	6	20,5 mm	350 bar 5075 psi	14 mm	6,4 mm 1/4"	1/8"
06110-04-04	MG0404	6	27 mm	450 bar 6500 psi	19 mm	6,4 mm 1/4"	1/4"
06110-04-06	MG0406	6	29 mm	450 bar 6500 psi	22 mm	6,4 mm 1/4"	3/8"
06110-04-08	MG0408	6	32 mm	450 bar 6500 psi	27 mm	6,4 mm 1/4"	1/2"
06110-05-04	MG0504	8	27 mm	350 bar 5075 psi	19 mm	7,9 mm 5/16"	1/4"
06110-05-06	MG0506	8	29 mm	350 bar 5075 psi	22 mm	7,9 mm 5/16"	3/8"
06110-05-08	MG0508	8	32 mm	350 bar 5075 psi	27 mm	7,9 mm 5/16"	1/2"
06110-06-04	MG0604	10	27 mm	450 bar 6500 psi	19 mm	9,5 mm 3/8"	1/4"
06110-06-06	MG0606	10	29 mm	450 bar 6500 psi	22 mm	9,5 mm 3/8"	3/8"
06110-06-08	MG0608	10	32 mm	450 bar 6500 psi	27 mm	9,5 mm 3/8"	1/2"
06110-08-06	MG0806	13	29 mm	415 bar 6010 psi	22 mm	12,8 mm 1/2"	3/8"
06110-08-08	MG0808	13	33 mm	415 bar 6010 psi	27 mm	12,8 mm 1/2"	1/2"
06110-08-10	MG0810	13	34,5 mm	415 bar 6010 psi	30 mm	12,8 mm 1/2"	5/8"
06110-08-12	MG0812	13	36 mm	415 bar 6010 psi	32 mm	12,8 mm 1/2"	3/4"
06110-10-08	MG1008	16	33 mm	350 bar 5075 psi	27 mm	16 mm 5/8"	1/2"
06110-10-10	MG1010	16	34,5 mm	350 bar 5075 psi	30 mm	16 mm 5/8"	5/8"
06110-10-12	MG1012	16	36 mm	350 bar 5075 psi	32 mm	16 mm 5/8"	3/4"
06110-10-16	MG1016	16	40 mm	350 bar 5075 psi	38 mm	16 mm 5/8"	1"
06110-12-08	MG1208	20	34 mm	350 bar 5075 psi	27 mm	19 mm 3/4"	1/2"
06110-12-10	MG1210	20	36 mm	350 bar 5075 psi	30 mm	19 mm 3/4"	5/8"
06110-12-12	MG1212	20	37 mm	350 bar 5075 psi	32 mm	19 mm 3/4"	3/4"
06110-12-16	MG1216	20	40 mm	350 bar 5075 psi	38 mm	19 mm 3/4"	1"
06110-16-12	MG1612	25	38 mm	280 bar 4060 psi	32 mm	25,4 mm 1"	3/4"
06110-16-16	MG1616	25	40 mm	280 bar 4060 psi	38 mm	25,4 mm 1"	1"
06110-16-20	MG1620	25	45 mm	210 bar 3045 psi	50 mm	25,4 mm 1"	1" 1/4
06110-20-20	MG2020	32	46 mm	210 bar 3045 psi	50 mm	31,8 mm 1" 1/4	1" 1/4
06110-20-24	MG2024	32	46 mm	210 bar 3045 psi	55 mm	31,8 mm 1" 1/4	1" 1/2
06110-24-24	MG2424	38	46 mm	185 bar 2683 psi	55 mm	38,1 mm 1" 1/2	1" 1/2
06110-24-32	MG2432	38	53 mm	185 bar 2683 psi	70 mm	38,1 mm 1" 1/2	2"
06110-32-32	MG3232	50	54 mm	165 bar 2393 psi	70 mm	50,8 mm 2"	2"
